Service Manual
26” Fireplace
With 3-Stage Remote
Model Number:
DF2600
UL Part Number
6901170859
6901170959
6901181300
7400430000R00
In keeping with our policy of continuous product development, we reserve the right to make changes without notice.
© 2011 Dimplex North America Limited
Dimplex North America Limited
1367 Industrial Road Cambridge ON Canada N1R 7G8
1-888-346-7539 www.dimplex.com
REV PCN DATE
00 - 21-SEP-11
IMPORTANT SAFETY INFORMATION: Always read this manual rst before attempting to service this
replace. For your safety, always comply with all warnings and safety instructions contained in this
manual to prevent personal injury or property damage.
Przeglądanie stron 0
1 2 3 4 5 6 ... 14 15

Podsumowanie treści

Strona 1 - Service Manual

Service Manual26” Fireplace With 3-Stage RemoteModel Number:DF2600UL Part Number6901170859690117095969011813007400430000R00In keeping with our policy

Strona 2 - TABLE OF CONTENTS

10 www.dimplex.comMOMENTARY ON/OFF SWITCHTools Required: Phillips head screwdriver. WARNING: If the replace was operatin

Strona 3 - OPERATION

11POWER CORD REPLACEMENTTools Required: Phillips head screwdriverNeedle nosed pliers WARNING: If the replace was operating prior to servicing allow

Strona 4 - MAINTENANCE

12 www.dimplex.comASSEMBLY COMPONENT PICTURESEXTERIOR VIEW OF MANUAL CONTROLSFront Grille OpenFlame MotorLight SocketsINTERIO

Strona 5 - FIREPLACE SURFACE CLEANING

13INTERIOR VIEW OF LEFT SIDE, TOP & FRONT PANELFlame Speed Control Board Terminal BlockMain Power ON/OFF SwitchPotentiometers (ame speed & di

Strona 6 - Replacement Parts List

14 www.dimplex.comPROBLEM CAUSE SOLUTIONGeneralCircuit breaker trips or fuse blows when unit is turned onShort in unit wiring

Strona 7 - WIRING DIAGRAM

15PROBLEM CAUSE SOLUTIONHeater ContinuedHeater is not turning on Improper operation Refer to Operation SectionDefective heater assembly Replace heater

Strona 8 - FLAME SPEED CONTROL

2 www.dimplex.comAlways use a qualied technician or service agency to repair this replace.! NOTE: Procedures and technique

Strona 9 - FLAME MOTOR/FLAME ROD

3 Pressing the switch for a third time (“–” position) • the ame effect remains on, the heater is set to the high heat setting, and all three red indi

Strona 10 - HEATER ASSEMBLY REPLACEMENT

4 www.dimplex.comMAINTENANCE WARNING: If the replace was operating prior to servicing allow at least 10 minutes for light

Strona 11 - REMOTE RECEIVER BOARD

5Hold the socket while screwing in the new bulb.4. UPPER LIGHT BULB REQUIREMENTS: Quantity of 2 clear chandelier or candelabra bulbs with an E-12 (sm

Strona 12 - ASSEMBLY COMPONENT PICTURES

6 www.dimplex.comEXPLODED PARTS DIAGRAMReplacement Parts List GLASS, TEMPERED BRONZE1. . . . . . . 5900000100RPGRILLE LOUVE

Strona 13

7WIRING DIAGRAM

Strona 14 - TROUBLESHOOTING GUIDE

8 www.dimplex.comMAIN ON/OFF SWITCH REPLACEMENT Tools Required: Phillips head ScrewdriverSlip Joint PliersFlat Head Screwdri

Strona 15 - PROBLEM CAUSE SOLUTION

9top cover: 2 on the left; 2 on the right; 2 on the back. Remove the top, placing it upside down on the top of the unit being careful not to damage a
